This ironing machine/Calender is suitable for surface ironing of products such as spray bonded wadding, non glue bonded wadding, needle punched felt, geotextile, and felt base fabric.
Usage characteristics: Suitable for surface heat treatment of non-woven fabrics to achieve the required thickness and smoothness of the product. Electric heating is used, and each heating roller is controlled by an independent motor. It has two structural forms: single-roller pre-ironing and double-roller main ironing. It has automatic temperature control and digital temperature display. Ironing machines (calenders, hot rolling machines) are mainly used to iron the surface of various velvet fabrics such as acrylic blankets, artificial fur, woolen, fine imitation plush and other products. The fabrics after ironing treatment The surface is soft and fluffy, and the pile is straight and bright, comparable to natural fabrics.
Working Width: 3600mm
Working Speed: 18--25m/min
The ironing roller is made of 28mm seamless steel pipe with a diameter of 560mm
Heating Mode: Electric heating tube/thermal oil (controllable silicon controlled temperature)
Surface Temperature：Cmax=220℃
Main Features:
(1)This machine is a double-sided ironing machine that achieves the specified thickness of the product through high-temperature treatment.
(2)Upper drum electric lifting, single motor control, convenient and adjustable.
(3)High input and low output "S" type threading of wadding, with each heating roller controlled by a separate motor.
(4) Two ironing rollers on top and bottom, controlled by sampling thyristor, with a through hole conductive ring.
(5)Heating Mode: Electric heating tube/thermal oil (controllable silicon controlled temperature)
